UB section tables
Use this page for universal beam searches common in UK, Australian, and export-market steelwork where UB designations are used instead of IPE or W shapes.
2,037
section rows
1
focus families
4
regional sources
Section data tables
Select a section category, choose the section type, then filter dimensions, section properties, and material strength data in one place.
Loading
size rows
27
material grades
Universal beam sections for common British and Australian structural steel framing.
0 of 0 rows shown
Grade 300 strength bands and tolerances for beams.
1
selected specs
3
yield bands
2
grades
3 of 3 thickness bands shown
| Material | Strength | Ductility and toughness | Tolerances | |||||
|---|---|---|---|---|---|---|---|---|
| Material | Standard | Grade | Thickness range | Yield strength | Tensile strength | Min. elongation | Min. Charpy V-notch | Dimensions and tolerances |
| AS 3679.1 | AS 3679.1 | Grade 300 | <=11 mm | 320 N/mm2 | min. 440 N/mm2 | 22% | 27 J at 0 deg C | AS 3679.1 |
| AS 3679.1 | AS 3679.1 | Grade 300 | >11 - <40 mm | 300 N/mm2 | min. 440 N/mm2 | 22% | 27 J at 0 deg C | AS 3679.1 |
| AS 3679.1 | AS 3679.1 | Grade 300 | >=40 mm | 280 N/mm2 | min. 440 N/mm2 | 22% | 27 J at 0 deg C | AS 3679.1 |
