Angle size tables
Use this page for steel angle searches covering equal leg angles, unequal leg angles, cleats, bracing, frames, ladders, and support details.
2,037
section rows
2
focus families
6
regional sources
Section data tables
Select a section category, choose the section type, then filter dimensions, section properties, and material strength data in one place.
Loading
size rows
26
material grades
Equal leg angle sections for bracing, frames, cleats, ladders, and miscellaneous steel.
0 of 0 rows shown
Grade 300 strength bands and tolerances for angles.
1
selected specs
3
yield bands
2
grades
3 of 3 thickness bands shown
| Material | Strength | Ductility and toughness | Tolerances | |||||
|---|---|---|---|---|---|---|---|---|
| Material | Standard | Grade | Thickness range | Yield strength | Tensile strength | Min. elongation | Min. Charpy V-notch | Dimensions and tolerances |
| AS 3679.1 | AS 3679.1 | Grade 300 | <=11 mm | 320 N/mm2 | min. 440 N/mm2 | 22% | 27 J at 0 deg C | AS 3679.1 |
| AS 3679.1 | AS 3679.1 | Grade 300 | >11 - <40 mm | 300 N/mm2 | min. 440 N/mm2 | 22% | 27 J at 0 deg C | AS 3679.1 |
| AS 3679.1 | AS 3679.1 | Grade 300 | >=40 mm | 280 N/mm2 | min. 440 N/mm2 | 22% | 27 J at 0 deg C | AS 3679.1 |
